Triple Bottom Line in Open Source

One of the more thought provoking things that came out of the OpenStack leadership training at Zingerman's last year, was the idea of the Triple Bottom Line. It's something I continue to ponder regularly.

The Zingerman's family of businesses definitely exist to make money, there are no apologies for that. However, it's not their only bottom line that they measure against they've defined for themselves. Their full bottom line is "Great Food, Great Service, Great Finance." In practice this means you have to ensure that all are being met, and not sacrifice the food and service just to make a buck.

If you look at Open Source through this kind of lens, a lot of trade offs that successful projects make make a lot more sense. The TBL for OpenStack would probably be something like: Code, Community, Contributors. Yes, this is about building great code, to make a great cloud, but it's also really critical to grow the community, and mentor and grow individual contributors as well. Those contributors might stay in OpenStack, or they might go on to use their skills to help other Open Source projects be better in the future. All of these are measures of success.

This was one of the reasons we recently switch the development tooling in OpenStack (DevStack) to using systemd more natively. Not only did it solve a bunch of long standing technical issues, that had really ugly work arounds, but it also meant enhancing our contributors. Systemd and the journal are default in every new Linux environment now, so skills that our contributors gained working with DevStack would now directly transfer to any Linux environment. It would make them better Linux users in any context, not just OpenStack. It also makes the environment easier for people coming from the outside to understand, because it looks more like what they are used to.

While I don't have enough data to back it up, it feels like this central question is really important to success in Open Source: "In order to be successful in this project you must learn X, which will be useful in these other contexts outside of the project." X has to be small enough to be learnable, but also has to be useful in other contexts, so time invested has larger payoffs. That's what growing a contributor looks like, they don't just become better at your project, they become a better developer for everything they touch in the future.

Lumosity boosts brain function by 0%

In the new controlled, randomized trial involving 128 healthy young adults, researchers found that playing Lumosity brain-training games for 30-minute sessions, five times a week for 10 weeks resulted in participants getting better at playing the games. But researchers saw no changes in participants’ neural activity and no improvements in their cognitive performance beyond those seen in controls. The same went for participants who played video games not designed with cognitive benefits in mind.

Source: Lumosity boosts brain function by 0%, the same as normal video games—study | Ars Technica UK

To the best of any studies out there, brain training games are all snake oil. There is no such thing as general intelligence booster, there is just getting better at specific skills because you do them more.

Traffic Shed for Solar Eclipse

This infographic summarizes how many people are expected to travel to the path of totality and where they will congregate. The patterns of converging lines to the path of totality represent the quickest drive paths from throughout the nation to the path. These lines are color-coded by destination state. The blue circles in the path are destinations for eclipse travelers, proportionally sized to the expected traffic impact. The black dots are metropolitan areas throughout the country scaled to population.

Source: Statistics — Total solar eclipse of Aug 21, 2017

This traffic shed diagram is interesting on so many levels. You can imagine what the congestion points might be on day of with an extra 2 million people trying to get around South Carolina.

It will also be interesting as the media starts ramping up as we get closer if more folks will decide to take this plunge, or figure that they'll be around in 7 years to catch the next one.

The 2017 Eclipse Impact on the Grid

On Monday, August 21, 2017, a total solar eclipse will pass over the Pacific Northwest (Oregon, Idaho, Wyoming etc.). The California balancing authority area will be affected by a partial eclipse between 9:02 AM and 11:54 AM PPT. As a partial eclipse, the sun will be obscured from 76% in Northern California to 62% in Southern California border area. The reduction in solar radiation will directly affect the output of the photovoltaics (PV) generating facilities and rooftop solar.

From the California ISO 2017 Solar Eclipse Report.

In looking up 2017 Eclipse stuff, I wondered if anyone had modeled the Solar Power generation drops during it. Of course they had, and I quickly found this California ISO report on it. California will probably be hit harder than this than most given their solar install base, so accurate modeling is really important.

I have yet to find anyone modeling wind for the event. As that definitely does pick up with the temperature shifts pretty heavily right around the event. But maybe it's too little of an impact to notice?



IoT & Home Assistant at OpenWest

I'm thrilled to be talking about the Internet of Things and Home Assistant at the OpenWest conference next week. The talk for it has come together quite nicely, and I'll hopefully be giving it a few more places over the coming year as well. The goal of the talk is to explain some of the complexity of the space, and see why it is so complex, and why the only real path forward in the short / medium term is an open source hub at the heart of everything.

For those that can't make it all the way to Utah, there is a trimmed down Article version of it up at opensource.com. The article seems to be doing well, and was #2 for this week on the site.

I will also be forever indebted to Benjamin Walker and his complete throw away line "this is why we can't have the internet of nice things" during his New York After Rent series (which is really incredible, and completely unrelated to any of this), which stuck in my brain for months afterwards, and became the seed of inspiration for this talk.

Much warmer summers

The map above, based on a new analysis from the Climate Impact Lab, shows how 95-degree days (35 degrees Celsius) are expected to multiply this century if countries take moderate climate action. In this scenario, countries would take some measures, but not drastic ones, to curb emissions — roughly the trajectory of the current pledges under the Paris climate agreement.

The resulting global warming would still cause significant shifts for many cities. In Washington, from 1986 to 2005, an average of seven days each year had temperatures of at least 95 degrees. By the end of the century, the city can expect 29 of these extremely hot days per year, on average. (The likely range is 14 to 46 hot days per year.)

Source: 95-Degree Days: How Extreme Heat Could Spread Across the World - The New York Times

Good analysis on what the impacts of the hotter days coming are going to be. 95 F is as reasonable an arbitrary measuring point as anything else, we're approaching body temperature there. The article looks at the world under the Paris agreement, as well as without it. The differences are striking.

Interestingly, commercial crop yields (specifically corn and soybeans) start to drop after 84 F. I hadn't realized that, but it makes sense. That's how hotter days, even without drought, have negative impacts on our food supply.

Hacking Windmills

Staggs sat in the front seat and opened a MacBook Pro while the researchers looked up at the towering machine. Like the dozens of other turbines in the field, its white blades—each longer than a wing of a Boeing 747—turned hypnotically. Staggs typed into his laptop's command line and soon saw a list of IP addresses representing every networked turbine in the field. A few minutes later he typed another command, and the hackers watched as the single turbine above them emitted a muted screech like the brakes of an aging 18-wheel truck, slowed, and came to a stop.

Source: Researchers Found They Could Hack Entire Wind Farms | WIRED

In a networked world, you need cyber security everywhere. Especially when physical access is so easy to get. The BeyondCorp model of not trusting the network is a really good starting place for systems like this.

Visualizing Watson Speech Transcripts

After comparing various speech to text engines, and staring at transcripts, I got intrigued about how much more metadata I was getting back from Watson about the speech. With both timings and confidence levels I built a little visualizer for the transcript that colors things based on confidence, and attempts to insert some punctuation:

This is a talk by Neil Gaiman about how stories last at the Long Now Foundation.

Things are more red -> yellow based on how uncertain they are.

A few things I learned along the way with this. Reversing punctuation into transcriptions of speech is hard. Originally I was trying to figure out if there was some speech delay that I could guess for a comma vs. a period, and very quickly that just turned into mush. The rule I came up with which wasn't terrible is to put a comma in for 0.1 - 0.3s delays, and put one period of an elipsis in for every 0.1s delay in speech for longer pauses. That gives a sense of the dramatic pauses, and does mentally make it easier to read along.

It definitely shows how the metadata around speech to text can make human understanding of the content a lot easier. It's nice that you can get that out of Watson, and it would be great if more environments supported that.











Comparing Speech Recognition for Transcripts

I listen to a lot of podcasts. Often months later something about one I listened to really strikes a chord, enough that I want to share it with others through Facebook or my blog. I'd like to quote the relevant section, but also link to about where it was in the audio.

Listening back through one or more hours of podcast just to find the right 60 seconds and transcribe them is enough extra work that I often just don't share. But now that I've got access to the Watson Speech to Text service I decided to try to find out how effectively I could use software to solve this. And, just to get a sense of the world, compare the Watson engine with Google and CMU Sphinx.

Input Data

The input in question was a lecture from the Commonwealth Club of California - Zip Code, not Genetic Code: The California Endowment's 10 year, $1 Billion Initiative. There was a really interesting bit in there about spending and outcome comparisons between different countries that I wanted to quote. The Commonwealth Club makes all these files available as mp3, which none of the speech engines handle. Watson and Google both can do FLAC, and Sphinx needs a wav file. Also it appears that all speech models are trained around the assumption of a 16kHz sampling, so I needed to down sample the mp3 file and convert it. Fortunately, ffmpeg to the rescue.

Watson

The Watson Speech to Text API can either work over websocket streaming or with bulk HTTP. While I had some python code to use the websocket streaming for live transcription, I was consistently getting SSL errors after 30 - 90 seconds. A bit of googling hints that this might actually be bugs on the python side. So I reverted back to the bulk HTTP upload interface using example code from the watson-developer-cloud python package. This script I used to do it is up on github.

The first 1000 minutes of transcription are free, so this is something you could reasonably do pretty regularly. After that it is$0.02 / minute for translation.

When doing this over the bulk interface things are just going to seem to have "hung" for about 30 minutes, but it will eventually return data. Watson seems like it's operating no faster than 2x real time for processing audio data. The bulk processing time surprised me, but then I realized that with the general focus on real time processing most speech recognition systems just need to be faster than real time, and optimizing past that has very diminishing returns, especially if there is an accuracy trade off in the process.

The returned raw data is highly verbose, and has the advantages of having timestamps per word, which makes finding passages in the audio really convenient.

So 30 minutes in I had my answer.

Google

I was curious to also see what the Google experience was like, which I originally did through their API console quite nicely. Google is clearly more focused on short bits of audio. There are 3 interfaces: sync, async, and streaming. Only async allows for greater than 60 seconds of audio.

In the async model you have to upload your content to Google Storage first, then reference it as a gs:// url. That's all fine, and the Google storage interface is stable and well documented, but it is an extra step in the process. Especially for content I'm only going to have to care about once.

Things did get a little tricky translating my console experience to python... 3 different examples listed in the official documentation (and code comments) were wrong. The official SDK no longer seems to implement long_running_recognize on anything except the grpc interface. And the google auth system doesn't play great with python virtualenvs, because it's python code that needs a custom path, but it's not packaged on pypi. So you need to venv, then manually add more paths to your env, then gauth login. It's all doable, but it definitely felt clunky.

I did eventually work through all of these, and have a working example up on github.

The returned format looks pretty similar to the Watson structure (there are only so many ways to skin this cat), though a lot more compact, as there isn't per word confidence levels or per word timings.

For my particular problem that makes Google less useful, because the best I can do is dump all the text to the file, search for my phrase, see that it's 44% of the way through the file, and jump to around there in the audio. It's all doable, just not quite as nice.

CMU Sphinx

Being on Linux it made sense to try out CMU Sphinx as well, which took some googling on how to do it.

Then run it with the following:

Sphinx prints out a ton of debug stream on stderr, which you want to get out of the way, then the transcription should be sent to a file. Like with Watson, it's really going only a bit faster than real time, so this is going to take a minute.

Converting JSON to snippets

To try to compare results I needed to start with comparable formats. I had 2 JSON blobs, and one giant text dump. A little jq magic can extract all the text:

Comparison: Watson vs. Google

For the purpose of comparisons, I dug out the chunk that I was expecting to quote, which shows up about half way through the podcast, at second 1494.98 (24:54.98) according to Watson.

The best way I could think to compare all of these is start / end at the same place, word wrap the texts, and then use wdiff to compare them. Here is watson (-) vs. google (+) for this passage:

one of the things that they [-it you've-] probably all [-seen all-]
{+seem you'll+} know that [-we're the big spenders-] {+where The Big
Spenders+} on [-health care-] {+Healthcare+} so this is per capita
spending of [-so called OECD-] {+so-called oecd+} countries developed
countries around the world and whenever you put [-U. S.-] {+us+} on
the graphic with everybody else you have to change the [-axis-]
{+access+} to fit the [-U. S.-] {+US+} on with everybody else
[-because-] {+cuz+} we spend twice as much as {+he always see+} the
[-OECD-] average [-and-] {+on+} the basis on [-health care-]
{+Healthcare+} the result of all that spending we don't get a lot of
bang for our [-Buck-] {+buck+} we should be up here [-we're-] {+or+}
down there [-%HESITATION-] so we don't get a lot [-health-] {+of
Health+} for all the money that we're spending we all know that that's
most of us know that [-I'm-] it's fairly well [-known-] {+know+}
what's not as [-well known-] {+well-known+} is this these are two
women [-when Cologne take-] {+one killoran+} the other one Elizabeth
Bradley at Yale and Harvard respectively who actually [-our health
services-] {+are Health Services+} researchers who did an analysis
[-it-] {+that+} took the per capita spending on health care which is
in the blue look at [-all OECD-] {+Alloa CD+} countries but then added
to that per capita spending on social services and social benefits and
what they found is that when you do that [-the U. S.-] {+to us+} is no
longer the big [-Spender were-] {+spender or+} actually kind of smack
dab in the middle of the pack what they also found is that spending on
social services and benefits [-gets you better health-] {+Gets You
Better Health+} so we literally have the accent on the wrong syllable
and that red spending is our social [-country-] {+contract+} so they
found that in [-OECD-] {+OCD+} countries every [-two dollars-] {+$2+}
spent on [-social services-] {+Social Services+} as [-opposed to
dollars-] {+a post $2+} to [-one-] {+1+} ratio [-in social service-]
{+and Social Service+} spending to [-health-] {+help+} spending is the
recipe for [-better health-] {+Better Health+} outcomes [-US-] {+us+}
ratio [-is fifty five cents-] {+was $0.55+} for every dollar [-it
helps me-] {+of houseman+} so this is we know this if you want better
health don't spend it on [-healthcare-] {+Healthcare+} spend it on
prevention spend it on those things that anticipate people's needs and
provide them the platform that they need to be able to pursue
[-opportunities-] {+opportunity+} the whole world is telling us that
[-yet-] {+yeah+} we're having the current debate that we're having
right at this moment in this country about [-healthcare-] {+Healthcare
there's+} something wrong with our critical thinking [-so-] {+skills+}

Both are pretty good. Watson feels a little more on target, with getting axis/access right, and being more consistent on understanding when U.S. is supposed to be a proper noun. When Google decides to capitalize things seems pretty random, though that's really minor. From a content perspective both were good enough. But as I said previously, the per word timestamps on Watson still made it the winner for me.

Comparison: Watson vs Sphinx

When I first tried to read the Sphinx transcript it felt so scrambled that I wasn't even going to bother with it. However, using wdiff was a bit enlightening:

one of the things that they [-it you've-] {+found that you+} probably
all seen [-all-] {+don't+} know that [-we're the-] {+with a+} big
spenders on health care [-so this is-] {+services+} per capita
spending of so called [-OECD countries-] {+all we see the country's+}
developed countries {+were+} around the world and whenever you put
[-U. S.-] {+us+} on the graphic with everybody else [-you have-] {+get
back+} to change the [-axis-] {+access+} to fit the [-U. S.-]
{+u. s.+} on [-with everybody else because-] {+the third best as+} we
spend twice as much as {+you would see+} the [-OECD-] average [-and-]
the basis on health care the result of all [-that spending-] {+let
spinning+} we don't [-get-] {+have+} a lot of bang for [-our Buck-]
{+but+} we should be up here [-we're-] {+were+} down [-there
%HESITATION-] {+and+} so we don't [-get a lot-] {+allow+} health [-for
all the-] {+problem+} money that we're spending we all know that
that's {+the+} most [-of us know that I'm-] {+was the bum+} it's
fairly well known what's not as well known is this these [-are-]
{+were+} two women [-when Cologne take-] {+one call wanted+} the other
one [-Elizabeth Bradley-] {+was with that way+} at [-Yale-] {+yale+}
and [-Harvard respectively who actually our health-] {+harvard
perspective we whack sheer hell+} services researchers who did an
analysis it took the per capita spending on health care which is in
the blue look at all [-OECD-] {+always see the+} countries [-but
then-] {+that it+} added to that [-per capita-] {+for capital+}
spending on social services [-and-] {+as+} social benefits and what
they found is that when you do that the [-U. S.-] {+u. s.+} is no
longer the big [-Spender-] {+spender+} were actually kind of smack dab
in the middle [-of-] the [-pack-] {+pact+} what they also found is
that spending on social services and benefits [-gets-] {+did+} you
better health so we literally [-have the-] {+heavy+} accent on the
wrong [-syllable-] {+so wobble+} and that red spending is our social
[-country-] {+contract+} so they found that [-in OECD countries-]
{+can only see the country's+} every two dollars spent on social
services as opposed to [-dollars to one ratio in-] {+know someone
shone+} social service [-spending to-] {+bennington+} health spending
is the recipe for better health outcomes [-US ratio is-] {+u. s. ray
shows+} fifty five cents for every dollar [-it helps me-] {+houseman+}
so this is we know this if you want better health don't spend [-it-]
on [-healthcare spend it-] {+health care spending+} on prevention
[-spend it-] {+expanded+} on those things that anticipate people's
needs and provide them the platform that they need to be able to
pursue [-opportunities-] {+opportunity+} the whole world is [-telling
us that-] {+telecast and+} yet we're having [-the current debate
that-] {+a good they did+} we're having right at this moment in this
country [-about healthcare-] {+but doctor there's+} something wrong
with our critical thinking [-so-] {+skills+}

There was an pretty interesting Blog post a few months back comparing similar Speech to Text services. His analysis used raw misses to judge accuracy. While that's a very objective measure, language isn't binary. Language is the lossy compression of a set of thoughts/words/shapes/smells/pictures in our mind over a shared medium audio channel and attempted to be reconstructed in real time in another mind. As such language, and especially conversation, has checksums and redundancies.

The effort required to understand something isn't just about how many words are wrong, but what words they were, and what the alternative was. Axis vs. access, you could probably have figured out. "Spending to" vs. "bennington", takes a lot more mental energy to work out, maybe you can reverse it. "Harvard respectively who actually our health" (which isn't even quite right) vs. "harvard perspective we whack sheer hell" is so far off the deep end you aren't ever getting back.

So while its mathematical accuracy might not be much worse, the rabbit holes it takes you down pretty much scramble things beyond the point of no return. Which is unfortunate, as it would be great if there was an open solution in this space. But it does get to the point that for good speech to text you not only need good algorithms, but tons of training data.

Playing with this more

I encapsulated all the code I used for this in a github project, some of it nicer than others. When it gets to signing up for accounts and setting up auth I'm pretty hand wavy, because there is enough documentation on those sites to do it.

Given the word level confidence and timestamps, I'm probably going to build something that makes an HTML transcript that's marked up reasonably with those. I do wonder if it would be easier to read if you knew which words it was mumbling through. I was actually a little surprised that Google doesn't expose that part of their API, as I remember the Google Voice UI exposing per word confidence levels graphically in the past.

I'd also love to know if there were ways to get Sphinx working a little better. As an open source guy, I'd love for there to be a good offline and open solution to this problem as well.

This is an ongoing exploration, so if you have any follow on thoughts or questions, please leave a comment. I would love to know better ways to do any of this.





James Bessen: "Learning by Doing: The Real Connection between Innovation, Wages, and Wealth"

Interesting video by the Author of "Learning by Doing: The Real Connection between Innovation, Wages, and Wealth", which largely comes down to "it's complicated". Sometimes automation replaces jobs, but sometimes it increases jobs, especially when there was pent up demand.

ATMs actually increased the number of bank teller jobs, because it led to needing less people needed per branch, and banks openned up new branches to meet pent up demand. It's also why manufacturing jobs are never coming back, we've met the demand on consumption, and most industries making goods are in the optimizing phase.

What's also really interesting is the idea that new skills are always undervalued, because there is no reliable basis to understand how valuable they are. The transition from typesetting to digital publishing was a huge skill shift, but was pretty stagnant on wages.

Exploring and discovering how things are more complicated, with a focus on climate and software
